Please Contact Us to Order to offer competitive prices and delivery time for RTK Regeltechnik - WENr.8112518-020 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | RTK Regeltechnik |
| Product | WENr.8112518-020 |
| Internal code | ONR4051169 |
| Technical specification | Motorized control valve - series MV 5274 three-way design for mixing application, shortened B-flange nominal diameter DN 25, pressure rating PN 16 body made of spheroidal graphite iron EN-GJS-400-18-LT flanges according to DIN spindle packing: bellows seal with safety stuffing box PTFE/white characteristic / flow direction: linear / - mixing cone, metal sealing kvs-value = 9,2 m³/h, stroke 15 mm seat diameter 25 mm surface treatment with zinc dust primary coat max. allowed pressure according to DIN EN 1092 max. allowed temperature TS 350 °C Electric actuator - type REact 30E-074 actuating force 3 kN, incl. handwheel for manual operation single-phase motor 230 V, 50/60 Hz actuating speed 0.74 mm/s, stroke 15 mm protection rating IP 65 - additional limit switches (2 off) |
