Please Contact Us to Order to offer competitive prices and delivery time for RTK Regeltechnik - W.Nr. 110.020 / MV 5214 motor control valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | RTK Regeltechnik |
| Product | W.Nr. 110.020 / MV 5214 |
| Description | motor control valve |
| Internal code | ONR4893022 |
| Technical specification | Motor control valve - MV 5214 series in continuous form nominal size DN 50, nominal pressure PN 16 Housing material ductile iron EN-GJS-400-18-LT Flanges with DIN sealing surface Spindle sealing: Bellows with PTFE safety plug Characteristic/flow rate: equal percent/below the cone parabolic cone, metallic sealing Kvs value = 37 m³/h, stroke 30 mm Seat diameter 50 mm Surface treatment with zinc dust primer CE marking in accordance with Pressure Equipment Directive (PED) max. allowable pressure in accordance with DIN EN 1092 max. allowable temperature TS 350 °C Electrical actuator - type ReAct 30E-074 Positioning force 3 kN, including manual adjustment 230 V 50/60 Hz AC motor setting speed 0.74 mm/s, stroke 30 mm Protection class IP 65 additional equipment: - additional limit switches (2 pieces) - Potentiometer 1000 ohms |
