Please Contact Us to Order to offer competitive prices and delivery time for Ascon - X3-3155-0200/9999 Digital controller number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Ascon |
| Product | X3-3155-0200/9999 |
| Description | Digital controller |
| Internal code | ONR485302 |
| Weight | 0.25 |
| Custom code | 90321020 |
| Technical specification | Digital controller series X3 (unconfigured) Front: 96 x 48 mm DIN, depth 110 mm A-No.: G no.: X3-(A)(B)(C)(D)-(E)(F)(G)0 (A) Mesh 3: 85...264V 48/63Hz 5: 18.....28 V 48/63 Hz and 20...30 Vdc (B) Output OP1 - OP2 - OP3 - OP4 1: relay - relay - relay - logic 5: Triac (SSR) - Triac (SSR) - Relay - Logic 9: relay - relay - relay - relay (C) serial port 0: without 5: RS485 ModBus / Jbus (Slave) (D) Options 0: without 2: 3-point step (open-neutral-close) 5: External setpoint + continuous output (also control output) 7: ES + SA + 3pts. Step (open-neutral-close) (E) Target value / special function 0: without 2: start-up + timer 3: setpoint program (max. 6 segments) (F) Instruction Manual 0: Italian/English 1: French/English 2: German/English 3: Spanish/English (G) Front color 0: dark gray 1: beige - Input (configurable): * Measured value: thermocouples, Pt-100, mA, mV, V, deltaT * Power converter * 3 logic inputs * External setpoint (option) - Control behavior (configurable) * PID control with self-tuning * ON/OFF hysteresis control - Control characteristics (configurable) * Heating or cooling characteristics with up to 3 alarm outputs or * Heating/cooling characteristics with up to 2 alarm outputs - Simultaneous display of setpoint and actual value - Control output configurable as relay or logic signal - Ramp function (one setpoint ramp each for rising and falling setpoints) - Power limitation - scalable inputs for standard signals - Configuration via front keys - Handheld control device - 3 setpoints |
