Please Contact Us to Order to offer competitive prices and delivery time for Ascon - X3 3155 3200 Digital controller number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Ascon |
| Product | X3 3155 3200 |
| Description | Digital controller |
| Internal code | ONR4585675 |
| Custom code | 90321020 |
| Technical specification | Digital controller series X3 (unconfigured) Front: 96 x 48 mm DIN, depth 110 mm Type: X3-3155-3200/9999 A-no.: G no.: X3- (A) (B) (C) (D) - (E) (F) (G) 0 (A) network 3:85... 264 V 48/63 Hz 5:18... 28 V 48/63 Hz and 20... 30 Vdc (B) Output OP1 - OP2 - OP3 - OP4 1: Relay - relay - relay - logic 5: Triac (SSR) - Triac (SSR) - Relay - Logic 9: Relay - relay - relay - relay (C) serial interface 0: without 5: RS485 Modbus /Jbus (slave) (D) Options 0: without 2:3-pt step (open-neutral-close) 5: External setpoint value+continuous output (also regular output) 7: ES+SA+ 3pts Step (open-neutral-close) (E) Set value/special function 0: without 2: Startup+timer 3: Set point program (max. 6 segments) (F) User manual 0: Italian/English 1: French/English 2: German/English 3: Spanish/English (G) Front color 0: dark grey 1:beige - Input (configurable): * Measured value: thermocouples, Pt-100, mA, mV, V, deltat * Current transformers * 3 logic inputs * External set value (option) - Control behavior (configurable) * PID control with self-optimization * ON/OFF hysteresis control - Control characteristics (configurable) * heating or cooling characteristics with up to 3 alarm outputs or * Heating/cooling characteristics with up to 2 alarm outputs - simultaneous display of setpoint and actual value - Control output can be configured as a relay or logic signal - Ramp function (one set point ramp each for rising and falling setpoints) - power limitation - scalable inputs for standard signals - Configuration via front buttons - Handheld device - 3 set points |
