Please Contact Us to Order to offer competitive prices and delivery time for Bifold - XS08-08-ABBC1F4PS2-77G-24D-30-AL-10X3-X8 3/2 way manifold control unit number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Bifold |
| Product | XS08-08-ABBC1F4PS2-77G-24D-30-AL-10X3-X8 |
| Description | 3/2 way manifold control unit |
| Internal code | ONR4585303 |
| Custom code | 8481209090 |
| Technical specification | Item no [13731] 1/2" NPT - Manifold - XS08-08 Material:SS316L Operating temperature range: -60°C to +40°C (@T6) XS08-08 Manifold control unit 1/2 “, 1/2 “NPT connection A 2-way ball valve B non-return valve B non-return valve C1 1/2 inch NPT take-off F4 filter regulator (manual drain) with pressure gauge P 3/2-way SPR pneumatic valve (with pilot line stack capabilities), NC S2 FP03P - 3/2-way solenoid valve with manual override (M) . NC, direct acting 77G degree of protection: Cu-TR/IECEx, Ex d IIC Gb, Ex tb IIIC db T4/5/6 24D power supply 24V DC 30 Power consumption 3.0 watts AL seals Flourosilicone (-60°C to +90°C) 10X3 outlet pressure range 0.4 - 10 bar, filter element 20 - 30 μm X8 pressure gauge Ø50mm, 0-10bar, 1/8" NPT connection, glycerine filled gauge No exhaust flow control, exhaust breathers |
