Please Contact Us to Order to offer competitive prices and delivery time for RTK Regeltechnik - REact 30E-074 with actuator and valve. number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | RTK Regeltechnik |
| Product | REact 30E-074 with actuator and valve. |
| Internal code | ONR4011481 |
| Technical specification | Control valve Motorized control valve - MV 5274 series in three-way form for mixing, with short B-flange Nominal size DN 25, nominal pressure PN 16 Housing material nodular cast EN-GJS-400-18-LT Flanges with sealing surface according to DIN Spindle seal: Bellows with safety stuffing box PTFE Characteristic curve / flow: linear / - Mixing cone, metallic sealing Kvs value = 9.2 m³ / h, stroke 15 mm Seat diameter 32 mm Surface treatment with zinc dust primer Max. permissible pressure according to DIN EN 1092 Max. permissible temperature TS 350 ° C Electric actuator - type REact 30E-074 Positioning force 3 kN, including manual adjustment AC motor 230 V, 50/60 Hz Adjustment speed 0.74 mm / s, stroke 15 mm Protection class IP 65 Additional equipment: - additional limit switches (2 pieces) |
