40/16-D/V4-PT-ML/HC-V2 M20AM   - Badger Meter United States  Sales


Please Contact Us to Order to offer competitive prices and delivery time for Badger Meter - 40/16-D/V4-PT-ML/HC-V2 M20AM M2000 DN 40 dairy fitting Material and technical data: Measuring tube: Stainless steel 1.4571 Liner: PTFE Housing: stainless steel 1.4301 Protection class: IP 67 Connection: screw connection DIN 11851 / stainless steel 1.4571 (Dairy) Electrodes: Hasteloy C Min conductivity. 5 S / cm (20 S / cm demi. Water) Measuring range: 0.03 to 12 m / s Accuracy: ± 0,2% of reading ± 1 mm / s Nominal pressure: 16 bar Overall length: 225 mm Run transmitter: M2000 Mounting: built Housing: cast aluminum painted in IP 67 Display: LCD, 4 lines / 20 digits, backlit Outputs: Analog output 0/4 - 20 mA : Scalable pulse max. 10 kHz : Min / Max + Status + direction indicator Configuration: 3 buttons Interfaces: RS 232, Modbus RTU Leerrohrdet. : On off Supply: 85 - 265 VAC number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

BRAND Badger Meter
Product 40/16-D/V4-PT-ML/HC-V2 M20AM
Description M2000 DN 40 dairy fitting Material and technical data: Measuring tube: Stainless steel 1.4571 Liner: PTFE Housing: stainless steel 1.4301 Protection class: IP 67 Connection: screw connection DIN 11851 / stainless steel 1.4571 (Dairy) Electrodes: Hasteloy C Min conductivity. 5 S / cm (20 S / cm demi. Water) Measuring range: 0.03 to 12 m / s Accuracy: ± 0,2% of reading ± 1 mm / s Nominal pressure: 16 bar Overall length: 225 mm Run transmitter: M2000 Mounting: built Housing: cast aluminum painted in IP 67 Display: LCD, 4 lines / 20 digits, backlit Outputs: Analog output 0/4 - 20 mA : Scalable pulse max. 10 kHz : Min / Max + Status + direction indicator Configuration: 3 buttons Interfaces: RS 232, Modbus RTU Leerrohrdet. : On off Supply: 85 - 265 VAC
Internal code ONR117218
Weight 1
