Please Contact Us to Order to offer competitive prices and delivery time for Settima - GR70-SMT-800L Screw pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Settima |
| Product | GR70-SMT-800L |
| Description | Screw pump |
| Internal code | ONR4054773 |
| Custom code | 84136070 |
| Technical specification | screw pump 70 SMT 800 L Q/P (1450 rpm; 46mm²/s; 10bar) =407.34L/min/9.41kW, NPSH=2.83mWS Q/P (1450 rpm; 260mm²/s; 10bar) =415.54l/min/11.35kW, NPSH=3.68mWS GR70 = size SMT = pressure rating 80 bar 800L = nominal flow rate with cylindrical shaft ø32mm for mounting with pump housing and clutch Housing material aluminum SAE pressure port 3 3000psi Standard suction housing with SAE connection 31/2 3000psi Seal material NBR |
