| BRAND | B-COMMAND |
| Product | LAM 001 |
| Description | Cross lever limit switch series Lambda |
| Internal code | ONR573176 |
| Weight | 1 |
| Technical specification | Electrical Specifications: Number of contacts: 2 x 1NO+1NC, potential-free Type of contacts: snap-action switch, silver alloy, self-cleaning Rated operating voltage: 250V AC Rated insulation voltage: 250V AC Rated operational current: 16A (250V AC) Rated Thermal Current: 17.5A Connections: 2x1.0 mm² or 1x2.5 mm², screw connection Mechanical Specifications: Number of positions: 4, Multiturn Casing material: ZAMAK die-cast Degree of protection: IP65 Operating temperature ፦20°C... +70°C start-up speed: 3 m/s max. Cable entries: 3 x M20x1.5 openings, including 2 x cap Poles: 2 x 200 mm (aluminium), including zero marking |
