Please Contact Us to Order to offer competitive prices and delivery time for RTK Regeltechnik - MV 5391-P Engine control valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | RTK Regeltechnik |
| Product | MV 5391-P |
| Description | Engine control valve |
| Internal code | ONR1802350 |
| Weight | 36 |
| Technical specification | Replacement for model no. 16102131/010 in straight version, with pump freewheel Nominal size DN 50, nominal pressure PN 40 Body material cast steel EN-GP-240-GH flanges with sealing surface in accordance with DIN Spindle sealing: PTFE/carbon roof sleeves Curve/flow rate: equal percent/on the cone perforated cone with 10% freewheel, hardened (metallic sealing) Kvs value = 19 m³/h, stroke 30 mm Seat diameter 40 mm Surface treatment with zinc dust primer CE mark in accordance with the Pressure Equipment Directive (PED) max. allowable pressure according to DIN EN 1092 max. allowable temperature TS 200 °C Electric actuator - type ReAct 60E-045 Actuating force 6 kN, including manual adjustment AC motor 230 V, 50/60 Hz Operating speed 0.45 mm/s, stroke 30 mm Protection class IP 65 Additional equipment: - additional limit switches (2 pieces) - Potentiometer 1000 ohms |
