Please Contact Us to Order to offer competitive prices and delivery time for POMPE CUCCHI SRL - MX 150/C Bareshaft pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | POMPE CUCCHI SRL |
| Product | MX 150/C |
| Description | Bareshaft pump |
| Internal code | ONR4441993 |
| Technical specification | Pump type M0X150W0ADN0004 Body and cover in AISI 316 Mechanical seal in ceramic/graphite/FPM Shaft in AISI 316L and gears in AISI 316L with heat treatment Bushes in sintered material DU Pump without heating chamber and with heat treatment Bare Shaft Pump Rotation direction counterclockwise (view motor side) Liquid OIL Viscosity 50 mPas @ PT Liquid temperature 30°C Ambient temperature +5°C/+35°C Flow 9.000 Lt/h Suction pressure 0 BAR Discharge pressure 15 BAR Differetial pressure 15 BAR Connections orientation horizontal Connections 2" WELD IN Speed rotation 1450 rpm @ 50Hz Pump painting RAL gray 7010 ATEX rules confornity Cat. 2G - zone 1 - class temperature T4 |
