Please Contact Us to Order to offer competitive prices and delivery time for Steimel - SF 4/112 RD - LFM number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Steimel |
| Product | SF 4/112 RD - LFM |
| Internal code | ONR4684623 |
| Technical specification | A-SF4/112RD-LFM, pump unit, 2-16 bar 7.5 kW, 1500, 400/690V, 50Hz, IP55, F, B5, IE3, tropical insulation. ASF4-112RD161948R Dimension sheet: DPA054D-161948R Spare part list: DET054112RD-165R Suction and pressure connection: SAE 2 Case parts: EN-GJL-250 (GG-25) Waves: 16 Mn Cr S 5, egh. gears: EN-GJS-400-15 (GGG-40), ionized, helical Interlocking: noise-optimized Storage: multi-layer MD Shaft seal: radial shaft seal Elastomers: FKM Conveying medium: lubricating oil Viscosity: 50-5000 cSt Temperature: 10-60°C Flow rate: approx. 140/168 l/min. Pressure: 5 bar Speed: 1450/1750 rpm. Pressure relief valve Adjustment range: 2-16 bar Opening pressure: 8 bar Rotation direction: right Test run: yes, with HLPD 46 Coupling: BKUA065-2438-301 Pump support with foot: BLF054300168-01, with foot IJN300 and intermediate flange Three-phase motor: LDM132-04-070 (Birkenbeul) Power 1/2:7.5/8.6 kW Speed 1/2:1500/1800 rpm. Voltage/frequency 1/2:400/690 volts at 50 Hz Voltage/frequency 1/2:460 volt triangle at 60 Hz Efficiency class: IE3 with additional label (without IE3) for: Ambient temperature: 0... +50°C Voltage/frequency: 380-420/660-720 volts at 50/60 Hz 440-480 volts at 60 Hz Protection class: IP 55 Insulation class: F, excluding after B Special feature: increased tropical protection Engine with interior paint For 100% humidity 30 to 60g water m³ air (N20) Type: B 5 Paint: primed Type plate: ETY924-D-E—PE02 |
