Please Contact Us to Order to offer competitive prices and delivery time for RTK Regeltechnik - 16022264-010 Motorized control valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | RTK Regeltechnik |
| Product | 16022264-010 |
| Description | Motorized control valve |
| Internal code | ONR3813945 |
| Weight | 138 |
| Technical specification | Motorized control valve - series MV 5321 three-way design for mixing application nominal diameter DN 150, pressure rating PN 16 body made of spheroidal graphite iron EN-GJS-400-18-LT flanges according to DIN spindle packing: chevron rings PTFE/graphite characteristic / flow direction: linear / - mixing cone, metal sealing kvs-value = 333 m³/h, stroke 40 mm seat diameter 150 mm surface treatment with zinc dust primary coat CE-marking according PED max. allowed pressure according to DIN EN 1092 max. allowed temperature TS 250 °C Electric actuator - type REact 60E-045 actuating force 6 kN, incl. handwheel for manual operation single-phase motor 230 V, 50/60 Hz actuating speed 0.45 mm/s, stroke 40 mm protection rating IP 65 accessories: - additional limit switches (2 off) - digital valve positioner, type REpos with display input signal: 4..20 mA feedback signal: 4..20 mA effective direction: at 0 % input port B closed at 0 % input actuator spindle extended - potentiometer 1000 Ohm |
